| 11.1V NCM lithim-ion battery pack parameter | ||||||||||||||||||
| Cell type | 18650 NCM battery cell | |||||||||||||||||
| Cell capacity | 2500mAh | |||||||||||||||||
| Cell layout | 3S 6P | 3S 8P | 3S 10P | 3S 12P | 3S 14P | 3S 16P | 3S 18P | 3S 20P | 3S 22P | 3S 24P | 3S 26P | 3S 28P | 3S 30P | 3S 32P | 3S 34P | 3S 36P | 3S 38P | 3S 40P |
| Norminal voltage | 11.1V | |||||||||||||||||
| Norminal capacity | 15Ah | 20Ah | 25Ah | 30Ah | 35Ah | 40Ah | 45Ah | 50Ah | 55Ah | 60Ah | 65Ah | 70Ah | 75Ah | 80Ah | 85Ah | 90Ah | 95Ah | 100Ah |
| Discharge cut-off voltage | 8.4V | |||||||||||||||||
| Charge cut-off voltage | 12.6V | |||||||||||||||||
| BMS current | 15A | |||||||||||||||||
| BMS function | overdischarge, overcharge, short circuit protection & equalization function | |||||||||||||||||
| Discharge current | ≤15A | |||||||||||||||||
| Charge current | ||||||||||||||||||
| Depth of discharge | ≥95% | |||||||||||||||||
| Cycle life | 800~1000 cycles | |||||||||||||||||
| Dimension | Depends on the layout of battery cell, customizable | |||||||||||||||||
| Accessory Wire | Pair with 30cm 16# silica gel wire for postive and negative pole | |||||||||||||||||
| IP level | IP65 | |||||||||||||||||
| Warranty | 3 years | |||||||||||||||||
| Cell certification | IEC 62133, CB, BIS, RoHS, MSDS, UN38.3 | |||||||||||||||||
| Application | Solar street light, energy storage battery, backup power station, balanced car, portable medical appliances, cordless power tool, cordless home appliances, drone, children car | |||||||||||||||||
